ID5000 Series Smart Code Reader
The ID5000 Series Smart Code Reader is a high-performance industrial barcode reading solution powered by a multi-core deep learning processor. Designed for advanced code reading applications, this full-featured system combines strong processing capabilities with mechanical focus lenses and multiple configurable components to deliver reliable and accurate decoding performance. Supporting resolutions of up to 20 megapixels, the ID5000 Series Smart Code Reader is suitable for demanding industrial environments requiring precision barcode inspection and identification.
Multi-core Processing
The Smart Code Reading Camera adopts embedded multi-core algorithm. The reconstructed data stream is processed in parallel among the underlying CPU, FPGA, and DSP chips; multi-threading of shooting, positioning and decoding is realized, and the efficiency of collective auditing learning technology is improved by 3 times
High Accuracy & Wide View
Built for high accuracy and wider coverage, the system supports resolutions ranging from 1.6 MP to 12 MP, enabling superior barcode reading performance across large fields of view. Its advanced imaging capabilities allow a single device to handle tasks that would typically require multiple code readers, helping simplify complex automation systems while improving operational efficiency. These intelligent barcode reading solutions are available through JV Technosoft Pvt Ltd for industrial automation and machine vision applications.
PRODUCT LIST
| Product model | Resolution | Focal length | Max. reading speed | Max. frame rate | Certification | Product status |
|---|---|---|---|---|---|---|
| MV-ID5030M-08S-WBN | 2048 × 1536 | 8 mm (0.3") | 90 codes/sec | 60.0 fps | CE, RoHS, KC | Delisting Preparation |
| MV-ID5030M-12S-WBN | 2048 × 1536 | 12 mm (0.5") | 90 codes/sec | 60.0 fps | CE, RoHS, KC | Delisting Preparation |
| MV-ID5030M-16S-WBN | 2048 × 1536 | 16 mm (0.6") | 90 codes/sec | 60.0 fps | CE, RoHS, KC | Delisting Preparation |
| MV-ID5030M-25S-WBN | 2048 × 1536 | 25 mm (1.0") | 90 codes/sec | 60.0 fps | CE, RoHS, KC | Delisting Preparation |
| MV-ID5030M-00C-NNN | 2048 × 1536 | / | 90 codes/sec | 60.0 fps | CE, RoHS, KC | Delisting Preparation |
| MV-ID5050M-08S-WBN | 2560 × 2048 | 8 mm | 90 codes/sec | 40.0 fps | CE, RoHS, KC | Available |
| MV-ID5050M-12S-WBN | 2560 × 2048 | 12 mm | 90 codes/sec | 40.0 fps | CE, RoHS, KC | Available |
| MV-ID5050M-16S-WBN | 2560 × 2048 | 16 mm | 90 codes/sec | 40.0 fps | CE, RoHS, KC | Available |
| MV-ID5050M-25S-WBN | 2560 × 2048 | 25 mm | 90 codes/sec | 40.0 fps | CE, RoHS, KC | Available |
| MV-ID5060M-08S-WBN | 3072 × 2048 | 8 mm (0.3") | 90 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5060M-12S-WBN | 3072 × 2048 | 12 mm (0.5") | 90 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5060M-16S-WBN | 3072 × 2048 | 16 mm (0.6") | 90 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5060M-25S-WBN | 3072 × 2048 | 25 mm (1.0") | 90 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5060M-00C-NNN | 3072 × 2048 | -- | 90 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120M-00C-NNN | 4096 × 3072 | 84 codes/sec | 28.0 fps | CE, FCC, RoHS, KC | Available | |
| MV-ID5200PM-00C-NNN(V2.0) | 5120 × 3968 | 36 codes/sec | 20.0 fps | CE, FCC, RoHS, KC | Available | |
| MV-ID5250PM-00C-NNN | 5120 × 5120 | 45 codes/sec | 15.0 fps | CE, RoHS, KC | Available | |
| MV-ID5050XM-08M-RBN | 2432 × 2048 | 8 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-12M-RBN | 2432 × 2048 | 12 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-16M-RBN | 2432 × 2048 | 16 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-25M-RBN | 2432 × 2048 | 25 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-08L-RBN | 2432 × 2048 | 8 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-12L-RBN | 2432 × 2048 | 12 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5050XM-16L-RBN | 2432 × 2048 | 16 mm | 120 codes/sec | 92.0 fps | CE, RoHS, KC | Available |
| MV-ID5030M | 2048 × 1536 | 8 mm (0.3") | 90 codes/sec | 60.0 fps | CE, FCC, RoHS, KC | Available |
| MV-ID5120RM-08M-RBN | 4096 × 3024 | 8 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-12L-RBN | 4096 × 3024 | 12 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-08L-RBN | 4096 × 3024 | 8 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-25M-RBN | 4096 × 3024 | 25 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-16L-RBN | 4096 × 3024 | 16 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-16M-RBN | 4096 × 3024 | 16 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5120RM-12M-RBN | 4096 × 3024 | 12 mm | 30 codes/sec | 30.0 fps | CE, RoHS, KC | Available |
| MV-ID5200PM | 5120 × 3968 | 36 codes/sec | 20.0 fps | CE, FCC, RoHS, KC | Available | |
| MV-ID5200M | 5440 × 3648 | 36 codes/sec | 20.0 fps | CE, RoHS, KC | Available |
